SPE audio

D-12,12 channel professional audio digital mixer


This is an era of digital “talking”, and the transition from analog to digital mixers is a trend that cannot be ignored!

Core advantages of digital mixer:

D12 digital mixer is an all-digital “professional mixer” that SPE AUDIO of entering the digital mixer market

It combines a new concept of modern digital mixer and traditional operation.

The D12 digital mixer effectively integrates the digital mixer system with innovative design and powerful DSP functions, bringing users a very professional functional experience.

Product parameters:

1、12 channels of signal input (6 channels of MIC, 2 groups of stereo, 1 group of digital input-sound card / MP3 + optical fiber

2、Input processing-Input gain adjustment (electronic gain) pre-amplification, high and low pass filtering, 4-band parameter equalization, compressor, delay, input channel sound image balance adjustment

3、MIC input adopts digital gain adjustment (participate in memory recall)

4、+48V phantom power supply (MIC channel is turned on and off independently)

5、Input and output EQ ON/OFF

6、Stereo return input

7、Quick copy function of channel parameters

8、Each channel has a multi-function menu, mute button, and monitor button

9、Each channel is equipped with 100MM electric faders, signal lights, and peak lights (8 electric faders, 1 analog fader)

10、10 signal outputs (stereo LR main output, 6 AUX outputs, 1 stereo monitor output)

11、Output processing, high and low pass filtering, 13-band parameter equalization, compressor, delay, phase

12、Auxiliary output (pre-fader, post-fader)

13、Dual-track digital recording function

14、Dual-row 3 color 12-segment level indicator

15、Built-in sound card (MP3, PC play music directly)

16、4 shortcut scene recall modes, 12 scene storage

17、Storage and recall of user parameters (can be managed on the PC side)

18、Built-in two-way dual DSP effector

19、3.2 inch 400*240 high-definition touch color screen

20、FX pedal switch interface

22、Optical fiber input and output

22、Multi-operating system control software (IOS system, WINDOWS system) Chinese and English switching display

23、Support wired network port adjustment (or external router wireless adjustment)

24、Parameter lock function

Suitable For:

 *Conference rooms

 *Lecture halls

 *Multi-function halls

*Recording studios

*Commercial performances
